Bolt adjusting welding rotator change the center distance through bolt manual. They can be controlled with AC frequency converter. Which rotating speed is widely, advanced and reliable. We also can design the special type of the turning -rolls in accordance with the customer’s requirement.
DKG Welding Rotator | ||
| Model | Rated Loading（T） | Rated Loading（lb) |
| DKG-2 | 2 | 4500 lb |
| DKG-5 | 5 | 11000 lb |
| DKG-10 | 10 | 22000 lb |
| DKG-20 | 20 | 44000 lb |
| DKG-40 | 40 | 88100 lb |
| DKG-60 | 60 | 132000 lb |
| DKG-80 | 80 | 176000 lb |
| DKG-100 | 100 | 220000 lb |
| DKG-150 | 150 | 330000 lb |
| DKG-200 | 200 | 441000 lb |
| DKG-300 | 300 | 661000 lb |
| DKG-500 | 500 | 1102000 lb |
| DKG-800 | 800 | 1763000 lb |
DKG-1 Rated loading: 1T(1 drive+1 idler) Diameter range: 20-800mm Rotating speed:1100mm/min Power: 120w Voltage: 220V-1PH-50/60HZ | ||
DKG-3 Rated loading: 3T(1 drive+1 idler) Diameter range: 30-1200mm Rotating speed:100-1900mm/min Power: 370w Voltage: 220V-1PH-50 |
Bolt adjusting welding rotator change the center distance through bolt manual. They can be controlled with AC frequency converter. Which rotating speed is widely, advanced and reliable. We also can design the special type of the turning -rolls in accordance with the customer’s requirement.
DKG Welding Rotator | ||
| Model | Rated Loading（T） | Rated Loading（lb) |
| DKG-2 | 2 | 4500 lb |
| DKG-5 | 5 | 11000 lb |
| DKG-10 | 10 | 22000 lb |
| DKG-20 | 20 | 44000 lb |
| DKG-40 | 40 | 88100 lb |
| DKG-60 | 60 | 132000 lb |
| DKG-80 | 80 | 176000 lb |
| DKG-100 | 100 | 220000 lb |
| DKG-150 | 150 | 330000 lb |
| DKG-200 | 200 | 441000 lb |
| DKG-300 | 300 | 661000 lb |
| DKG-500 | 500 | 1102000 lb |
| DKG-800 | 800 | 1763000 lb |
DKG-1 Rated loading: 1T(1 drive+1 idler) Diameter range: 20-800mm Rotating speed:1100mm/min Power: 120w Voltage: 220V-1PH-50/60HZ | ||
DKG-3 Rated loading: 3T(1 drive+1 idler) Diameter range: 30-1200mm Rotating speed:100-1900mm/min Power: 370w Voltage: 220V-1PH-50 |
